YS-F50 Industry Transportation Platform Drone

The YS-F50 dual electric industrial transport heavy-load flight platform offers a 10-40 kg recommended load (max 50 kg), with a dual-battery system enabling 35-70 minutes of working time, compatible with its own flight platform.

Basic Parameters of the Rack

Product type: YS-F50 dual electric version industry application transportation heavy load flight platform
Product wheelbase: 2280mm
Product size:
- Unfolded: 1783 * 1783 * 729mm
- Folded: 950 * 910 * 923mm
Product weight:
- Rack weight: 14kg
- Maximum configuration (excluding battery and pendulum device): 34kg
- Including 18S44000mAh dual battery weight: 56kg
- Full load 30kg (takeoff weight): 86kg
Arm size: 46 * 50mm
Recommended weight: 10-40kg (maximum load capacity 50kg)
Fixed method: Plug-in dual electric version
Compatible model: YS-F50 dual electric version industry application flight platform
Flight Control: Boying Industry Edition Flight Control
Remote control: H16
Power system:
- Motor: X13
- Electrically adjustable: 200A
- Propeller: 56 inches
- Battery: 18S 44000mAh soft pack battery
Working time:
- Unloaded (takeoff weight 56kg, 18S44000mAh): 70 minutes
- Full load 30kg (86kg, 18S34400mAh): 35 minutes
- Load capacity 10kg (takeoff weight 66kg, 18S44000mAh): 55 minutes
